Circle Gear & Machine Company Co. offers extensive manufacturing capabilities for helical gears in diverse sizes, types, base materials, and shaft types. We can produce large-scale helical gears, measuring up to 120″ in diameter. Diametrical pitch can run to 1.25, with up to a 20 module. The minimum diametrical pitch of which we are capable is 32, and the gear face can measure up to 120″. Our full production capabilities include machining, heat treating, and finishing.
We can produce helical gears from metals like stainless steel and aluminum, as well as non-metal materials from phenolics to nylon. Shafts can be machined in flat or hex shapes, and we feature gear cutting capabilities like hobbing, milling and shaping. Our heat treating services include induction treating, nitriding, carburizing, and flame treating.
Custom Helical Gears Capabilities
| Diameter | Max 120 Inches |
|
| Diametrical Pitch | Min 32 DP | Max 1.25 DP |
| Module | 20 | |
| Face Width | Max 120 Inches | |
| General Capabilities | As Needed Contract Just-In-Time | Production Small Parts |
| Primary Capabilities | Finishing Heat Treating Machining |
|
| Materials | Acetal/Delrin Alloy Steel Aluminum Brass Bronze Carbon Steel Ductile Iron | Gray Cast Iron Nylon Plastic Phenolic Polycarbonate Polyester Stainless Steel |
| Industry Focus | Automotive Biotechnology Chemical Construction Electrical Electronics Food Processing HVAC Heating, Ventilation, and Air Conditioning Machinery Marine | Medical Mining Nuclear Oil, Gas, Petroleum Optical Packaging Pharmaceutical Plumbing Pneumatics Pulp & Paper Pumps Semiconductor |
| Shaft Feature | Flat Hex |
|
| Gear Cutting Method | Broaching Climb Hobbing Conventional Hobbing Flame Cutting | Milling Shaping |
| Gear Forming Method | Centrifugal Casting Die Casting Forging | Sand Casting |
| Gear Finishing Methods | Grinding Honing | Lapping Shaving |
| Heat Treatment Methods | Carburizing Flame | Induction Nitriding |
| Production Volume | Specialty Production Shop Prototype Low Volume Small Run | High Volume Large Run Long Run Large Scale Production Volume Run |
